Question It's Baffling...

How much does it effect the motorcycle when you take out the baffles, as far as carbs and engine performance?

SuperiorKolours is offline
Sponsored Links
Advertisement

post #2 of 12 (permalink) Old 11-06-2012, 04:54 PM
-AJ
Senior Member

-AJ's Avatar

Join Date: Feb 2011
Location: good ole' kentucky
Posts: 3,537
you wont gain any power. most likely you will lose power if you don't do anything with fuel and air also

I started out with nothin'... and i still got most of it left.

2006 Honda VTX-1300R
Memphis Shades Batwing, Stock "C" Model Pipes, Mustang Seat, Mustang Fender Bib, National Cycle Hard Bags,
Lindby Multibar, Küryakyn Sound System, Küry ISO Grips, Show Chrome Grille Cover, Küry L.E.D Light Kit, Küry Triple Whammy,
Küry Constellation Light Bar, TTO Tach, Metzeler Tires, Chromed Wheels and much, much more.

Last edited by -AJ; 11-06-2012 at 04:56 PM.
-AJ is offline
post #3 of 12 (permalink) Old 11-06-2012, 05:31 PM
Member

Join Date: Jul 2012
Posts: 378
Well you will allow more air out than what the bike is taking in to mix fuel etc. Without baffles, with jets, with the right mixture it will move your torque band more towards the upper rpm range than the mid to low it is at with baffles.

TCazes is offline
post #4 of 12 (permalink) Old 11-06-2012, 06:01 PM
Senior Member

Join Date: Nov 2008
Location: Visalia, CA
Posts: 5,377
We talking stock pipes or aftermarket. Eitherway it will be louder. if stock pipes might cause lean enough condition to need adjustment. If Amarket, probably will not affect tuning.

93 VT1100C Sleeper, VH Exhaust, Saddleman Seat, Baby Apes, Metzlers, 2mm sleeved and bored (1150cc),10.5:1 comp, Modified Heads, Valves, Cams, Adjustable Timing, Bored Carbs.
93gc40 is offline
post #5 of 12 (permalink) Old 11-07-2012, 01:48 AM Thread Starter
Member

SuperiorKolours's Avatar

Join Date: Oct 2012
Location: NC
Posts: 431
Garage
Quote:
Originally Posted by -AJ View Post
you wont gain any power. most likely you will lose power if you don't do anything with fuel and air also
Yeah, I didnt think I would gain any power, I meant more like do I need to rejet because of the removed baffles or is it not a big deal?

SuperiorKolours is offline
post #6 of 12 (permalink) Old 11-07-2012, 08:18 AM
Super Moderator

old dad's Avatar

Join Date: Oct 2008
Location: sc
Posts: 10,297
If only the baffles are removed on your vlx, you might get away with only having to adjust the a/f screw to get rid of any popping or backfiring on deceleration. That's all I had to do. If you fiddle around and change anything on the air filter you will likely need to re-jet the carb too.

2006 vlx
old dad is online now
post #7 of 12 (permalink) Old 11-07-2012, 09:12 AM
Senior Member

adlowe's Avatar

Join Date: Jun 2006
Location: Southeast Michigan
Posts: 7,685
Quote:
Originally Posted by TCazes View Post
Well you will allow more air out than what the bike is taking in to mix fuel etc.
No you won't. Taking the baffles out does NOT create a vacuum.

Art's 1999 Shadow 1100 ACE
.

Ride bell by Dr. Bob's Patient
adlowe is offline
post #8 of 12 (permalink) Old 11-07-2012, 11:41 AM
Senior Member

Join Date: Nov 2008
Location: Visalia, CA
Posts: 5,377
Quote:
Originally Posted by TCazes View Post
Well you will allow more air out than what the bike is taking in to mix fuel etc. Without baffles, with jets, with the right mixture it will move your torque band more towards the upper rpm range than the mid to low it is at with baffles.
Quote:
Originally Posted by adlowe View Post
No you won't. Taking the baffles out does NOT create a vacuum.

Actually, after the motor, the exhaust is the main restriction to the amount intake air flow. If you remove the baffles, intake flow Goes UP. Doesn't create vaccum just a bigger hole for the air to exit through. More air flow often means you'll need to adjust the AF mixture. In general increasing air flow will increase power, it also make the AF LEAN. You won't see any added POWER, but you might see better PERFORMANCE at speed, but a loss of torque off the line. Basically the available torque will move a little higher in the rev range. With your mods, the changes won't be much, we're talking tiny fractions of a # here..

93 VT1100C Sleeper, VH Exhaust, Saddleman Seat, Baby Apes, Metzlers, 2mm sleeved and bored (1150cc),10.5:1 comp, Modified Heads, Valves, Cams, Adjustable Timing, Bored Carbs.
93gc40 is offline
post #9 of 12 (permalink) Old 11-07-2012, 12:23 PM
Senior Member

adlowe's Avatar

Join Date: Jun 2006
Location: Southeast Michigan
Posts: 7,685
Quote:
Originally Posted by 93gc40 View Post
Actually, after the motor, the exhaust is the main restriction to the amount intake air flow. If you remove the baffles, intake flow Goes UP. Doesn't create vaccum just a bigger hole for the air to exit through.
Yes. But you will NOT get more out than the engine takes in -- as TCazes stated when he posted "Well you will allow more air out than what the bike is taking in to mix fuel etc."

Art's 1999 Shadow 1100 ACE
.

Ride bell by Dr. Bob's Patient
adlowe is offline
post #10 of 12 (permalink) Old 11-07-2012, 03:56 PM
Member

Join Date: Jun 2012
Location: Fayetteville, AR
Posts: 77
On my vt750 I didn't notice any real change except the sound. It now sounds like a motorcycle. No popping or backfiring or sputtering on decel. Did not notice any loss of power.

2009 Shadow Spirit VT750C2
2003 Harley Fatboy FLSTI
1985 Rebel CMX250C-Sold

DarkSpirit750 is offline
